| Specification | YZG-600 | YZG-800 | YZG-1000 | YZG-1400A | FZG-10 | FZG-15 | FZG-20 |
| Inside Dimension (mm) | φ600×976 | φ800×1247 | φ1000×1527 | φ1400×2054 | 1500×1060× 1220 | 1500×1400 ×1220 | 1500×1800 ×1220 |
| Outside Dimension (mm) | 1135×810× 1020 | 1700×1045× 1335 | 1693×1190× 1500 | 2380×1675× 1920 | 1924×1720 ×1513 | 1513×1924 ×2060 | 1924×2500 × 1513 |
| Drying Shelf Number | 4 | 4 | 6 | 8 | 5 | 8 | 12 |
| Shelf Distance (mm) | 81 | 82 | 102 | 102 | 122 | 122 | 122 |
| tray Dimension (mm) | 310×600×45 | 520×410×45 | 520×410×45 | 460×640×45 | 460×640 ×45 | 460×640 ×45 | 460×640 ×45 |
| Tray Number | 4 | 8 | 12 | 32 | 20 | 32 | 48 |
| Pressure Inside Rack (MPa) | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 | ≤0.784 |
| Drying Rack Temperatur (℃) | 35-150 | 35-150 | 35-150 | 35-150 | 35-150 | 35-150 | 35-150 |
| vacuum at Idle Inside Chamber (MPa) | -0.1 | -0.1 | -0.1 | -0.1 | -0.1 | -0.1 | 0.1 |
