Our specially designed tablet counting and filling machine can pack and count any type of tablets, capsules, caplets, soft capsules, round pills, and other solids.
What is Tablet Counting Machine
The automatic tablet counter is equipped with an easy-to-operate man-machine interface and advanced PLC, which can be easily controlled and operated. Besides, the control system also has the functions of "no product, no counting" and clearing broken bottles and tablets.
The high-speed PLC system accurately and quickly controls the entire process, including counting, filling, and monitoring. Automatic bottling and automatic filling through the conveyor belt, high identification rate, and fast response speed. The tablet counting machine can also be connected to some auxiliary equipment, such as a feeding turntable, capping machine, and labeling machine.
The tablet counter has a three-stage vibrating tray for filling tablets or capsules. The vibration frequency of each tray can be adjusted to achieve fast and stable feeding. Bottles are positioned and indexed by cylinders to ensure accurate positioning before filling to avoid overflow.
This fully automatic tablet and pill counter can automatically calculate the number of most oral solid pills, tablets, and capsules on the market with an accuracy of 99% or higher. Even if the counting machine is running at high speed, the advanced control system will not have technical errors and will continue to maintain reliable performance. The automatic pill counting machine service life can be as long as several decades.
Features of Tablet Counting Machine
● The machine is compact and easy to operate. ● Interactive and friendly man-machine interface and PLC system. ● It can count tablets or capsules of different sizes. ● A small neck or mouth bottle can be filled quickly to protect the product from damage. ● The tray is separated from the vibration drive system to protect the inside of the machine. ● Longer machine service cycle and 99% counting accuracy. ● The machine is easy to disassemble and can be adjusted at any time. ● The machine is easily connected with other equipment.
SP2500 Single Head Tablet Counting Machine
Applications of machines SP2500 single head tablet counting machine applies to manufacturers, health care products factory, a hospital preparation room for packaging tablets, pills, capsules & drugs counting and filling. It also can be applied to other sectors of the same shape counting materials, packaging purposes. The aircraft used a single mechanical transmission, a simple, smooth operation, simple structure, the advantages of stability.
Main Technical Parameters Counting device: one The size of Counting Plate (Inner diameter / Outer diameter): 25/520 mm Obliquity of Counting Plate : 0-45 °. Packaging specifications of Bottle:35-500 ml. Drugs diameter:5.5-18 mm. The main rotary speed: 6 r/ min. Capacity :6-36 bottle / min. Matching Motor: Model: Y90S-6. Power: 0.75KW. Speed: 910 r / min. Frequency: 50HZ. Voltage: 380 v. External dimensions: 700 * 800*1400 mm. net weight: 150 kg.
SP2-500 Two-head Tablet Counting Machine
SP2-500 automatic two-head tablet counting machines mainly are suitable for the pharmaceutical manufacturing plant. It uses the yellow Yuan bottle to pack tablets, pill medicinal preparation drugs count, fills installs the equipment. Also, it is suitable carries on the same shape to other professions material count, the packing uses.
This pharmacy pill counter machine adapts the many kinds of specification yellow Yuan bottle, may pack the multi- specifications piece, the tablet has the compatible strong characteristic. This function automatically installs, loses bottle working procedure, and so on completes the principle bottle, counts, fills, effectively reduces operates worker's labor intensity, improved the working efficiency. The tablet capsule counting machine uses the sole mechanical drive, has the operation simple, the revolution is steady, the structure is simple, works the stable merit.
The Main Technical Parameter Counting components: 2. Numbers of articles bobbins size (inside diameter / outer diameter) 25/470 millimeter. Number bobbin may the inclination angle: 0-45°. The package of bottling specification: 35-500 milliliter. Drugs diameter: 5.5-12 millimeters. Main rotational speeds : 6 revolutions / divide. The productivity: 6-36 bottle / divide. Necessary electrical machinery. Model: Y90S-6. Power: 0.75KW. The rotational speed: 910 revolutions of / frequency. Divisions rate: 50HZ. Voltage: 380 volts. External dimensions (long * width * are high): 2600*900*1700 millimeter. Machine only weight: 560 kilograms.
