| Item/Parameter | Model: LPG | |||||
| 5 | 25 | 50 | 100 | 150 | 200-2000 | |
| Inlet Temperature (℃) | 140~350 Can be adjusted manually | |||||
| Outlet Temperature (℃) | ~80-90 | |||||
| High Evaporation of Water (kg/h) | 5 | 25 | 50 | 100 | 150 | 200-2000 |
| Centrifugal Spray Head Rotational Form | compressed air drive | mechanical drive | ||||
| Rotate Speed (r.p.m) | 25000 | 18000 | 18000 | 18000 | 15000 | 8000-15000 |
| Spray Disc Diameter (mm) | 50 | 100 | 120 | 140 | 150 | 180-340 |
| Heat Source | electricity
| electricity + steam | electricity + steam, oil, gas | It depends on the situation | ||
| Electric Heating Power (KW ) | 9 | 36 | 63 | 81 | 99 |
|
| Size (m) | 1.8×0.93×2.2 | 3×2.7×4.26 | 3.7×3.2×5.1 | 4.6×4.2×6 | 5.5×4.5×7 | customized size |
| Dry powder recoveryDry powder recovery (%) | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 | ≥95 |
