Hot air circulation oven uses a low noise and high temperature proof axial flow blower and an automatic temperature control system.
What is Hot Air Drying Oven
The whole circulation system is the fully enclosed to make that the heat efficiency of the drying oven increases from 3~7% of the traditional drying oven to 35~45% of the present one. The highest heat efficiency can be up to 50%. The successful design of CT-C hot air circulation oven makes that the hot air circulation drying oven in our country reach the advanced level in the world. It saves energy and increases the economic benefit.
Most hot air is circulated in the oven. The Heat efficiency is high and the energy is saved. By using the forced ventilation function, there are adjustable air distribution plates inside the oven. The materials can be dried uniformly. The heating source might be steam, hot water, electricity and far infrared. The whole machine is low in the noise. The operation is in balance. The temperature is controlled automatically. The installation and maintenance are easy. The application is wide. The machine can be used for drying various materials and it is a common drying equipment.
Applications of Dry Oven Machine
This drying oven is suitable for the material and product hot solidification and dry de-watering in the pharmaceutical, chemical, food, farming, side-product, aquatic product, light industries, heavy industries and others industries. Such as: raw material medicine, crude drug, prepared herbal medicine of Chinese traditional medicine, plaster, powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, de-watering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish and etc.
Main Technical Parameters And Explanation
Hot Air Dehydrating Oven Features
1. Options of heat source: steam, electricity, or far infrared, or both steam electricity. 2. Drying temperature: steam heating 50-130 ℃ , Max.140 ℃ . 3. Electricity and far infrared:50-300 ℃ .Automatic control system and computer control system on request. 4. Commonly used steam pressure 0.2-0.8Mpa(2-8 bar). 5. For CT-C-I, electric heated, rated power consumption:15Kw, real consumption : 5-8Kw. 6. The special requirements should be indicated at the time of order. 7. Please consult as for any special requirements. 8. For operation temperature of over 140 ℃ or less than 60 ℃ , please indicate when order. 9. The ovens and baking trays made by our factory are uniform in dimensions, and can be exchanged each other. 10. Baking plate dimensions:460*640*45mm.
Telang drying ovens have a variety of sizes and heating devices to meet various industrial and lab drying applications.
Industrial Drying Oven Model ● RXH-0, 25 kgs/ time ● RXH-I, 100 kgs/ time ● RXH-II, 200 kgs/ time ● RXH-III, 300 kgs/ time ● RXH-IV, 400 kgs/ time
Lab Drying Oven Model ● RXH-4, 4 kgs/ time ● RXH-6, 6 kgs/ time ● RXH-8, 8 kgs/ time
How to Use A Tray Drying Oven
1. Put the solid material containing moisture on the oven tray, and then put the tray into the oven. 2. Start to run the oven machine and fresh air enters through the inlet. 3. The hot air is circulated by the fan, and the air in the chamber is heated by the heater. 4. Reduce the vapor pressure and reduce the thickness of the air boundary layer, thereby enhancing the drying effect of hot air. 5. Water diffuses from the inside of the porous material and evaporates from the surface of the solid substance. 6. The air that absorbs about 80-90% of the moisture from the material is recycled to the inlet of the fan and mixed with fresh dry air. 7. The hot air circulates many times to absorb more moisture on the material. 8. The moisture collected in the air is discharged through the outlet of the dryer. 9. Estimate the dryness of the material by measuring the water discharged from the outlet. 10. Finally, the drying tray is pulled out of the bin and sent to the unloading station.
