TEZP high speed rotary tablet press is a new generation high press for tablets, upgraded from the high speed tablet press. This equipment is designed and manufactured with rich experience in tablet press manufacturing for more than 40 years, redesigned with fresh, efficient and modern ideas for a better performance which is applicable for large-scale tablet production.
Model | TEZP35 | TEZP53 | TEZP55 | TEZP-57 |
Die model | IPT`D | IPT`B | IPT`B | IPT`B |
Max. capacity (per hour) | 189000 | 286200 | 297000 | 307800 |
Max speed (rpm) | 45 | 45 | 45 | 45 |
Max. tablet press diameter(mm) | 25 | 13 | 12 | 11 |
Max. filling depth(mm) | 18 | 18 | 18 | 18 |
Max. pressure(kN) | 100 | 100 | 100 | 100 |
Max. pre-pressure(kN) | 60 | 60 | 60 | 60 |
Main motor power(kW) | 11 | 11 | 11 | 11 |
Dimensions(Length mm× Width mm) | 1290×1170 | 1290x1170 | 1290x1170 | 1290x1170 |
Including hopper | 1900 | 1900 | 1900 | 1900 |
Weight(Kg) | 3500 | 3500 | 3500 | 3500 |
Branded name parts |
| |
PLC | SIEMENS | S7-224XP+EM231 |
Touch screen | SIEMENS | TP177B |
Inverter | SIEMENS | MM420-550W 380V |
Main motor | ABB |
|
Breaker | SIEMENS | 3VU1340-1MN00/3P |
Lubruation | BIJUR | VERSA III |
Parts | Material |
Upper enclosure | Plexiglass |
Upper rail guide enclosure | Stainless steel 0Cr18Ni9(304) |
Turntable | Cast iron HT250 45#(Surface nickel phosphorus) |
Hopper | Stainless steel 0Cr18Ni9(304) |
Punch | 6CrW2Si |
Die | Cr12 |
Panel enclosure | Stainless steel 0Cr18Ni9(304) |
