A high-efficiency tablet film coating machine is a special equipment for coating tablets, pills, water-phase films, and organic films. The film coating equipment is manufactured following the "GMP" standard of the pharmaceutical industry.
What Is Film Coating Machine
All its casings, coating drums (coating pans), hot air fans, spraying devices, and other parts in contact with medicines are made of stainless steel.
The entire operation process is controlled by the PLC programmable system, which realizes man-machine dialogue. It can also be controlled by manual operation. All coating operations are performed in a closed state without dust flying and spray liquid splashing. It is a new type of coating equipment with high quality, high efficiency, reliability, cleanness, energy-saving, and convenient operation.
1. Constant pressure variable peristaltic pump, no need for the oil return pipe. 2. Siemens PLC touch screen control, All parameters could be set on the control panel. 3. Sound insulation and heat insulation, which play an important role in heat preservation inside the machine. 4. The spray gun is uniformly atomized, the spray surface is large, the gun direction can be adjusted, and the nozzle has no dripping or clogging. 5. Promote oblique mixing, tumbling, and frequent exchange of materials to avoid debris tablets and improve outputting yield.
Main Components of Tablet Film Coating Machine
Host The machine's main body is equipped with PLC and touch screen, which can display temperature and negative pressure control system and can be customized programming. It can be set to automatically adjust the flow, negative pressure, air intake, exhaust, temperature, speed, etc.
Hot Air Cabinet The air sucked by the tablet film coater through the centrifugal fan is filtered first, and then blown to the drum of the host through the heat exchanger (steam or electric).
Exhaust Cabinet The exhaust cabinet is used to exhaust air from the pot of the host (including dust collection) and make the working area under negative pressure. The cabinet is equipped with a shock absorber, and the exhaust port is equipped with a backflow prevention device.
Agitating And Holding Tank It is equipped with a pneumatic agitator, which is driven by compressed air and has a stable rotation speed, which can evenly mix the tablets.
