The trough mixer is used to mix dry powder or paste materials to make different materials evenly mixed. It is a horizontal trough-shaped single paddle mixing type, and the stirring paddle is a through-shaft type, which is easy to clean.
Model | CH100 | CH200 | CH300 | CH400 | CH500 |
Volume(L) | 100 | 200 | 300 | 400 | 500 |
Capacity(kg) | 50 | 100 | 150 | 200 | 200 |
Mixing speed (r/min) | 24 | 24 | 24 | 24 | 24 |
Tilting angle of trough(°) | 360 | 360 | 360 | 360 | 360 |
Tilting speed of trough(r/min) | 9 | 9 | 9 | 9 | 9 |
Main Motor (KW) | 1.5 | 4 | 5.5 | 5.5 | 7.5 |
Vice Motor (KW) | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 |
Overall size (mm) | 1380*500*900 | 1670*600*1150 | 2150*700*1250 | 2280*800*1250 | 2400*900*1250 |
Weight(kg) | 270 | 600 | 750 | 780 | 820 |
